New turbo S410G 174260 1323649 1243759 0R7205 0R6990 turbocharger for CAT Industrial Truck 3456 3406C 3406E 14.64L engine

Product description:

Turbo Model : S410G 174260

Fuel : Diesel

Part Number : 174260

Brand Name : Booshiwheel

Displacement : 14.64L, 14640 ccm

KW : 372/500

OE number : 0R-6990 0R6990 0R-7205 0R7205 124-3759 1243759 132-3649 1323649

Year : 1994-01

Applications : 1994-01 Caterpillar Truck with 3406C, 3406E Engine

标签 : Turbocharger

Welcome to contact us :



Name: Cindy Yang

QQ: 3472219925

Wechat: + 86 18912392873

Whatsapp: + 86 17351503656

E-mail: Sales03@booshiwheel.com



Specification



Part Number 174260
OE number 0R7205, 132-3649, 1323649, 1243759, 124-3759, 0R6990
Year 1994-01
Description Truck
Manufacturer Part Number 471120-0001
CHRA 174248 (169062, 161-6780, 10R-0510, 0R7287, 451686-0006) $450.00 NEW IN STOCK, MADE IN USA
Turbo Model S410G
Prefix 4AS, 5EK, 6TS, 3LW
Displacement 14.64L, 14640 ccm
KW 372/500
Engine 3406C, 3406E, (Earlier 3406E)
Engine Manufacturer Caterpillar
Fuel Diesel
Engine speed 1800
Truck Engine 3406E
Industrial Engines 3456
S/N 5EK99999-99999, 6TS681-99999
Fuel Diesel
Bearing Housing 174246 NEW IN STOCK
Turbine Wheel 169346 (Ind. 81.74 mm, Exd. 91.44 mm, 10 Blades) NEW IN STOCK
Comp. Wheel (Hipped) 171691 (Ind. 74.57 mm, Exd. 105.3 mm, Trm 53, 7+7 Blades, Billet) $149.00 NEW IN STOCK
Back plate 167783 $47.75 NEW IN STOCK
Heat shield Number 167790 NEW IN STOCK
Repair Kit 318396 (318397)(1253400750) $89.90 NEW IN STOCK
Turbine Housing 1243762 $1269.05
Compressor Cover 1267966, 1963846 $734.39
Gasket Kit 318417 $14.00
174260 Up-graded 174259
NOTE The 174260 and the 177148 are very similar turbos, the wheel measurements are exactly the same, the only difference is the exhaust housing, the 174269 uses a W/G 1.10 A/R housing while the 177148 uses a 1.32 A/R housing the overall horsepower different between the two and what they will support is 100 hp, the larger housing allows the engine to breathe a little better and will support 600 hp versus 500 hp for the smaller housing.
Replaced By 471120-0001
Manufacturer Borg Warner - 3K - Schwitzer BWTS USA



Application:

1994-01 Caterpillar Truck with 3406C, 3406E Engine
