Product description:
Turbo Model : GT1752S Hyundai
Fuel : Diesel
Part Number : 710060-5001S
Brand Name : Booshiwheel
Engine Manufacturer : Hyundai
OE number : 28200-4A001, 282004A001
Year : 2000-
GT1752S 710060-5001S 28200-4A001 for Turbo Hyundai
| Part Number | 710060-5001S |
| Previous Version | 710060-0001, 710060-1 |
| OE number | 28200-4A001, 282004A001 |
| Year | 2000- |
| Description | Hyundai H-1 CRDI, Starex CRDI |
| CHRA | 433352-0032 (433352-5032S) |
| Turbo Model | GT1752LS, GT1752HLS, GT1752S |
| Engine | D4CB Euro-3, D4CB |
| Engine Manufacturer | Hyundai |
| Displacement | 2.5L, 2476 ccm, 4 Cylinders |
| KW | 86/140 HP |
| RPM Max | 4000 |
| Fuel | Diesel |
| Angle α (compressor housing) | 265 |
| Angle β (turbine housing) | 351 |
| Bearing Housing | 434578-0012 (Water Cooled)(replaces 434578-0012 Hyundai) |
| Turbine Wheel | 729099-0001 |
| Comp. Wheel | 702492-0001 |
| Back plate | 701335-0009 |
| Heat Shield | N/R |
| Repair Kit | 732252-0001 |
| Turbine Housing | 435788-0071 |
| Compressor Cover | 435791-0098 |
| Turbine Housing AR | 0.44 |
| Actuator | 432340-0116 |
| Settings Wastegate (pressure) | 1.300-1.340/1.507-1.546 bar |
| Settings Wastegate (lift shaft) | 1.00/4.00 mm |
| Gasket (turbine inlet) | 210564 |
| Gasket (turbine outlet) | 210565 |
| Gasket (oil outlet) | 210243 |
| Replaced By | 710060-9001 |
| Manufacturer | Honeywell-Garrett |
2000- Hyundai H-1 CRDI, Starex CRDI With D4CB Euro-3 Engine
