K03 53039700053 06A145713L turbo for AUDI, SKODA

Product description:

Turbo Model : 53039700053

Part Number : 53039700053

Brand Name : Booshiwheel

Displacement : 1.8L, 4 Cyl, 1781 ccm

KW : 110/150

OE number : 06A145713L

Year : 2000-05

Applications : 2000-05 turbo forAudi A3 with 1.8L-5V langs,along Engine 2000-05 turbo forSkoda Octavia with 1.8L-5V langs,along Engine

K03 53039700053  06A145713L turbo for AUDI, SKODA



product describtion

Part Number 53039700053  53039880053
Previous Version 53039880053
OE number 06A145704S, 06A145713L, 06A145713B
Year 00-05
Manufacturer Part Number 53039700058, 53039700053
CHRA 53037100516
Turbo Model K03-2075EYD5.88KCAXH
Engine 1,8-5V langs/along
Displacement 1.8L, 4 Cyl, 1781 ccm
KW 110/150 HP
RPM Max 5500
Fuel Gasoline
Angle α (compressor housing) 266.5
Angle β (turbine housing) 183.5
Bearing Housing 53041010017
Turbine Wheel 53031205037
Compressor Wheel 53041232029
Back plate / Seal plate 53041515712a
Heat shield / Shroud 53031652000
Service Kit, 53037110001
Turbine Housing 53031009078
Compressor Cover 53041015105
Turbine Housing AR 5
Actuator 58251104072















Product show


SNV33391 (2).jpgSNV33388.jpgSNV31184 (2).jpgSNV31182 (2).jpg
