Product description:
Turbo Model : TW7302 8V92TA
Fuel : Diesel
Part Number : 465987-5001S 465987-5001 465987-5001S 465987-9001, 465987-9001S 4659870001 4659875001 4659875001S 4659879001 4659879001S 465987-1
Brand Name : Booshiwheel
Engine Manufacturer : 6L71TI 8V92TA
Displacement : 12100 ccm, V8 Cylinders, 7000 ccm, 6 Cylinders
KW : 559/771 HP
RPM Max : 1800
OE number : 23503908 R23503908
Year : 465987-5001 465987-5001S 465987-9001 465987-9001S
Applications : Detroit Diesel Marine with 6L71TI Engine
Welcome to contact us :
Whatsapp / Wechat :+86 13606178432 Skype : jane.wang_15
QQ: 1127776325
Email:jane.wang@booshiwheel.com
Specification
| Part Number | 465987-5001S |
| Previous Version | 465987-5001, 465987-5001S, 465987-9001, 465987-9001S, 4659870001, 4659875001, 4659875001S, 4659879001, 4659879001S, 465987-1 |
| OE number | 23503908, R23503908 |
| Description | Marine |
| CHRA | 442032-0024 (442032-9024S)(23504211, R23504211) $1,433.56 NEW IN STOCK, MADE IN USA |
| Turbo Model | TW7302 |
| Engine | 6L71TI, 8V92TA |
| Displacement | 12100 ccm, V8 Cylinders, 7000 ccm, 6 Cylinders |
| KW | 559/771 HP |
| RPM Max | 1800 |
| Fuel | Diesel |
| Angle α (compressor housing) | 340º |
| Angle β (turbine housing) | 138º |
| Bearing Housing | 442028-0001 (8925742, 08925742)(Oil Cooled) $206.08 NEW IN STOCK |
| Turbine Wheel | 442029-0020 (23502111)(Ind. 84.79 mm, Exd. 96.85 mm, 11 Blades)(1101675436) $389.60 NEW IN STOCK |
| Comp. Wheel | 441829-0002 (8925745, 4P3815)(447033-0003)(Ind. 75.36mm, Exd. 102.25 mm, 6+6 Blades, Superback) $92.80 NEW IN STOCK |
| Back plate | 442027-0001 (8925746) $154.46 NEW IN STOCK |
| Heat shield Number | 407657-0004 (409794-0000)(9N2037, 9N3701, 8925757)(1101680340) $22.00 NEW IN STOCK |
| Repair Kit | 468267-0000 (23514215)(1101678752) $91.60 NEW IN STOCK |
| Turbine Housing (Water Cooled) | 409339-0201 (23504212) $1,981.86 NEW IN STOCK |
| Compressor Cover | 441880-0001 (8925753) $481.75 NEW IN STOCK |
| Turbine Housing AR | 1.03 |
| Gasket oil inlet | 129119 (201049, 9737, 1S6595, 210019-0000, 409266-0003, 3819900)(1900000035) (Paper) $4.48 |
| Gasket (oil outlet) | 129120 (210018-0000, 409267-0002, 3709738, 3500682, 201048, 1S4810, 9988, 9738, 3519763)(1900000025) $4.38 |
| Gasket (turbine inlet) | 409038-0001 (409038-0000, 1S4295, 132040, 205396, 202873, 3500683, 1215736, 210017-0000, 210835-0000, 9749)(1900000003) $15.49 |
| Gasket (turbine inlet) | 210255 (Copper layers) |
| NOTE | Partially restricted |
| Manufacturer | Honeywell-Garrett, BTW USA |
Detroit Diesel Marine with 6L71TI Engine
1989- Detroit Diesel Marine Engine (Pleasure Craft) with 8V92TA Engine
